Produktbeskrivning
The Victron MultiPlus 12/500/20-16 VE.Bus is a compact and highly reliable inverter/charger combination designed for campervans, motorhomes, boats, and off-grid power systems.
It combines a pure sine wave inverter (230V / 430W) with a powerful 12V battery charger (20A) in one efficient unit, delivering seamless power conversion and intelligent energy management wherever you travel.
POWERFUL ALL-IN-ONE SYSTEM
The MultiPlus combines three essential functions:
- Pure sine wave inverter (clean 230V output)
- Advanced 12V battery charger (20A)
- High-speed automatic AC transfer switch
This makes it ideal for systems that need reliable shore power integration and off-grid independence.
POWERASSIST TECHNOLOGY
The intelligent PowerAssist feature prevents overload of limited AC sources such as:
- Campsite hook-up (shore power)
- Small generators
If demand exceeds available input power, the MultiPlus automatically:
- Reduces battery charging current
- Supplements power using the battery when needed
This ensures uninterrupted power supply without tripping fuses or overloads.
RELIABLE 230V POWER ANYWHERE
With a pure sine wave output, the MultiPlus safely powers sensitive electronics such as:
- Laptops and chargers
- Coffee machines
- Refrigerators
- Power tools
- Medical devices
No noise, no instability—just clean grid-quality power.
INTELLIGENT BATTERY CHARGING
The built-in charger supports multiple battery types:
- Lithium (LiFePO4)
- AGM
- Gel
- Flooded lead-acid
Features include:
- Adaptive 3-stage charging
- Temperature compensation
- Safe and efficient charging from shore power or generator
SCALABLE SYSTEM DESIGN
The MultiPlus can be expanded for larger systems:
- Parallel operation (up to 6 units)
- Three-phase configuration
- Split-phase operation
Perfect for advanced camper builds or full off-grid installations.
EASY CONFIGURATION & INTEGRATION
Configuration options include:
- DIP switch basic setup
- Full programming via MK3-USB interface
- Remote configuration via GX device + VRM portal
Fully compatible with Victron ecosystem including Cerbo GX and SmartSolar MPPT controllers.
IDEAL FOR
- Campervan conversions
- Motorhomes
- Boats & marine systems
- Off-grid cabins
- Tiny houses
- Backup power systems
TECHNICAL SPECIFICATIONS
| Specification | Value |
|---|---|
| Model | Victron MultiPlus 12/500/20-16 |
| Battery Voltage | 12V |
| Inverter Output | 230V AC |
| Continuous Power | 430W |
| Peak Power | 900W |
| Charger Current | 20A |
| AC Input Range | 187–265V AC |
| Frequency | 45–65 Hz |
| DC Input Range | 9.5–17V |
| Dimensions | 311 × 182 × 100 mm |
| Weight | 4.4 kg |
| Communication | VE.Bus |
